General
Brand
Hikvision
Model
Hikvision DS-2CE11D0T-PIRL
Usage
Indoor & Outdoor
Type
Bullet CC Camera
Part No
DS-2CE11D0T-PIRL
Camera
Mega Pixels
2.0MP
Resolutions.
1080P
Max. Camera Resolution
1920 x 1080
Signal System
PAL/NTSC
Shutter Time
1/25s to 1/50,000s (PAL), 1/30s to 1/50,000s (NTSC)
Sensor Type.
2MP progressive scan CMOS
Day & Night
IR Cut Filter
Night Vision
Yes
Lens
Field of View
103 Degree (H)/82.2 Degree (H)
Lens Type
2.8 mm, 3.6 mm fixed focal lens
Lens Mount
M12
Lens Adjustment Range
Pan: 0 degree - 360 degree, Tilt: 0 degree - 180 degree, Rotation: 0 degree - 360 degree
AGC
Low/middle/high
Function
Brightness, Contrast, Sharpness, Saturation, DNR, Mirror
Capture Distance
Unmentioned
Technical Info
Camera Type
Fixed
Video Output
1 HD analog output
Synchronization
Internal Synchronization
Visual Alarm
Yes
PIR Range
110degree (Angle), 11m (Range)
IR Range
20 Meter
Protocols
HIKVISION-C (TVI output)
Communication
Up the coax
Ingress Protection
IP67
Physical Description
Form-Factor
Bullet
Body Color
White
Body Material
Metal
Dimensions
68 x 70 x 179.8mm
Weight (Kg)
345gm
Recommended Accessories (Not Included)
1. DVR, 2. Power adapter: 121.761.07 K2 Power adapter For CC camera (White), 3. Coaxial Cable: 121.130.05 Value Top RG59 CCTV coaxial cable with 2 power wire Black (1 Meter), 4. BNC Connector: 121.761.03 K2 BNC Connector for CC Camera, 5. Harddisk: 04.046.13 Toshiba 1TB 3.5 Inch SATA 7200RPM Desktop HDD #DT01ACA100/HDWD110UZSVA, 6. Monitor: 08.020.39 HP V194 18.5 Inch LED Monitor (V5E94AA), 7. Power Strip: 48.421.01 Many MTS-144 4 Port Power Strip
Power
Power Supply
12 VDC+-25%
Power Consumption
Max. 4.5 W
Warranty
Warranty Details
1 year
Additional Info
Night Vision Mode
Black and White
Audio
None
Feature
2 MP high performance CMOS, 1920 ?? 1080 resolution, 2.8 mm, 3.6 mm fixed focal lens, PIR detection, visual alarm, EXIR 2.0, smart IR, up to 20 m IR distance, IP67, Up the coax (HIKVISION-C)
Others
Day& Night: IR cut filter, Horizontal Field of View: 103.5degree (2.8 mm), 80.3degree (3.6 mm), D/N Mode: Auto/Color/BW (Black and White), Auto White Balance: ATW/MANUAL, White Light: Alarm/Off, Day/Night Mode: Auto/Color/BW (Black and White), White Balance: Auto/Manual, Backlight Compensation: Yes, Language: English, Chinese, Operating Condition: -40 degree C to 60 degree C, humidity: 90% or less (non-condensation), Night Vision: IR cut filter
Specialty
PIR detection, visual alarm, EXIR 2.0, smart IR, up to 20 m IR distance
Country Of Origin
China
Made in/ Assemble
China
Quick Overview
Brand - Hikvision, Model - Hikvision DS-2CE11D0T-PIRL, Usage - Indoor & Outdoor, Type - Bullet CC Camera, Form-Factor - Mini Bullet, Camera Type - Fixed, Field of View - 82.2 Degree - 103 Degree, Mega Pixel - 2.0MP, Resolution - 1080P, Max. Camera Resolution - 1920 x 1080, Signal System - PAL/NTSC, Shutter Time - 1/25s to 1/50,000s (PAL), 1/30s to 1/50,000s (NTSC), Lens - 2.8 mm, 3.6 mm fixed focal lens, Lens Mount - M12, Lens Adjustment Range - Pan: 0 degree - 360 degree, Tilt: 0 degree - 180 degree, Rotation: 0 degree - 360 degree, Sensor Type - 2MP progressive scan CMOS, Day & Night - IR Cut Filter, Night Vision - Yes, AGC - Low/middle/high, Video Output - 1 HD analog output, Function - Brightness, Contrast, Sharpness, Saturation, DNR, Mirror, Synchronization - Internal Synchronization, Visual Alarm - Yes, PIR Range - 110degree (Angle), 11m (Range), IR Range - 20 Meter, Protocol - HIKVISION-C (TVI output), Communication - Up the coax, Ingress Protection - IP67, Body Color - White, Power Supply - 12 VDC+-25%, Body Material - Metal, Dimension - 68 x 70 x 179.8mm, Weight (Kg) - 345gm, Feature - 2 MP high performance CMOS, 1920 ?? 1080 resolution, 2.8 mm, 3.6 mm fixed focal lens, PIR detection, visual alarm, EXIR 2.0, smart IR, up to 20 m IR distance, IP67, Up the coax (HIKVISION-C), Others - Day& Night: IR cut filter, Horizontal Field of View: 103.5degree (2.8 mm), 80.3degree (3.6 mm), D/N Mode: Auto/Color/BW (Black and White), Auto White Balance: ATW/MANUAL, White Light: Alarm/Off, Day/Night Mode: Auto/Color/BW (Black and White), White Balance: Auto/Manual, Backlight Compensation: Yes, Language: English, Chinese, Operating Condition: -40 degree C to 60 degree C, humidity: 90% or less (non-condensation), Part No - DS-2CE11D0T-PIRL, Recommended Accessories (Not Included) - 1. DVR, 2. Power adapter: 121.761.07 K2 Power adapter For CC camera (White), 3. Coaxial Cable: 121.130.05 Value Top RG59 CCTV coaxial cable with 2 power wire Black (1 Meter), 4. BNC Connector: 121.761.03 K2 BNC Connector for CC Camera, 5. Harddisk: 04.046.13 Toshiba 1TB 3.5 Inch SATA 7200RPM Desktop HDD #DT01ACA100/HDWD110UZSVA, 6. Monitor: 08.020.39 HP V194 18.5 Inch LED Monitor (V5E94AA), 7. Power Strip: 48.421.01 Many MTS-144 4 Port Power Strip, Warranty - 1 year, Country of Origin - China, Made in/ Assemble - China
