Gigabyte Genuine GA-H61M-S(Small) Intel Desktop Motherboard
Location: Jatra-Bari-Dhaka
Rate this product!
General
Model
Gigabyte GA-H61M-S
Chipset
Intel H61 Express
Form Factor
Micro ATX
Warranty
3 year
Country Of Origin
Taiwan
Made in/ Assemble
China
Compatibility
Sockets Supported
LGA1155
Supported CPU
Intel Core i7 / i5 / i3 / Pentium / Celeron processors
Generation
3rd
Supported Operating System
Windows 7 / 8 / 8.1 / XP
Memory Support
Memory Type
DDR3
Memory MHz
1333/ 1066/ 800MHz
Memory Channel
Dual
Memory Slot
2
Memory Max.
16GB
Optane Memory Support
No
Graphics
Graphics
Integrated Graphics
Multi-GPU Support
No
PCI Express Slot
1 x PCI Express x16 slot, running at x16, 1 x PCI Express x1 slot
CrossFire Support
No
Sli Support
No
Storage
Storage Interface
3Gb/s
SATA Port
4 x SATA
Raid Support
No
Network & Connectivity
LAN Chipset
Realtek GbE LAN
LAN Speed (Mbps)
10/100/1000Mbps
Ports
USB Port
8 x USB2.0
VGA Port
1
Audio
Audio Chipset.
Realtek ALC887
Audio Channel
2/4/5.1/7.1
Bios Information
BIOS Type
1 x 32 Mbit flash
BIOS Model
AMI EFI BIOS
BIOS Version
PnP 1.0a, DMI 2.0, SM BIOS 2.6, ACPI 2.0a
Additional Info
Brand
Gigabyte
Chipset Brand
Intel
WiFi
No
Bluetooth
No
DisplayPort (DP)
No
FireWire
No
TPM Port
No
COM Port
No
Feature
Q-Flash, Xpress Recovery2, EasyTune, Humidity Protection PCB design, Electrostatic Protection and Power Failure Protection design, Unique On/Off Charge delivers the best recharging capability to iPad, iPhone and iPod Touch, Supports 3rd generation PCI-Express interface, Enhanced Intel HD Graphics 2000/3000 integrated with the processor
Others
1 x CPU fan header, 1 x system fan header, 1 x speaker header, 1 x chassis intrusion header, 1 x Clear CMOS jumper, 3 x audio jacks (Line In, Line Out, Mic In)
Quick Overview
Gigabyte GA-H61M-S
CPU Sockets - LGA1155
Chipset - Intel H61 Express
Generation - 3rd/2nd
Memory Channel - Dual Channel
