hdmi splitter 1 in 4 out hdmi switch splitter 4 way hdmi splitter
Location: Elephant-Road-Dhaka
Rate this product!
hdmi splitter 1.4 version 1 in 4 out hdmi switch splitter 4 way hdmi splitter MT-SP104M
The MT-SP104M HDMI Splitter is the perfect solution for anyone who needs to send one source of digital high definition video to four HDMI displays at the same time. It supports all HDMI-enabled equipment, such as DVD players, satellite set-top boxes and all HDMI displays.
Connects one HDMI source to two HDMI displays at the same time
HDMI (3D, Deep, Color) HDCP Compatible
Supports resolutions of up to 1080p Full HD
Support EDID
Supports Dolby True HD and DTS HD Master Audio
Long distance transmission – up to 15 m (24 AWG)
Supports up to 225MHz bandwidth for high performance video
Signaling rates up to 3.4 Gbits
Plug-and-play – no software installation required"
| Video Input | Interface | 1 x HDMI Type A Female (Black) |
| Impedance | 100 Ω | |
| Max distance | 15 m | |
| Video Output | Interface | 4 x HDMI Type A Female (Black) |
| Impedance | 100 Ω | |
| Video | Max. data rate | 10.2 Gbps (3.4 Gbps Per Lane) |
| Max. pixel clock | 340 MHz | |
| Compliance | HDMI (3D, Deep Color, 4K); | |
| HDCP Compatible | ||
| Max resolutions | Up to 1920*1440@60Hz (4:2:0) | |
| Max distance | Up to 15 m | |
| Audio | Input | 1 x HDMI Type A Female (Black) |
| Output | 4x HDMI Type A Female (Black) | |
| Power | Connector: | 1 x DC Jack |
| Consumption: | 5 VDC, 14.84W | |
| Environment | Operating Temp. | -5-55 °C |
| Storage Temp. | -20-60℃ | |
| Humidity | 5-90% RH, Non-Condensing | |
| Housing | Metal | |
| Weight | 0.45kg | |
| Dimensions(L x W x H) | 9.5 x 6 x 2 cm | |
