Sensor | 1/3″ HR color CCD image sensor |
Number of Pixels | 976(H) x 494(V) / 976(H) x 582(V) |
Min. Illumination | 0.1 Lux; 0 Lux (IR ON) |
S/N Ratio | More than 48dB (AGC off) |
Electronic Shutter | 1/60 (1/50) to 1/100,000 sec. |
Lens | f3.6mm / F2.0 |
Lens Angle | 14 |
IRIS Mode | AES |
IR LED | 21 units |
IR Effective Distance | Up to 15 Meters |
White Balance | ATW |
Operating Temperature | 0℃~40℃ |
Video Output | 1.0 Vp-p composite, 75Ω |
Power Source (±10%) | DC12V |
Current / Power consumption (±10%) | 70mA (IR OFF), 200mA (IR ON) |
Dimensions (mm) | 94.1(Θ) x 70.7(H) |
Net Weight | 0.178 kg |
Warranty | One Year |
