CB-IP130B
Pick up Element 1/3? AR0130 1.3 Megapixel CMOS Sensor
Picture Element 1280 (H) x 960 (V)
Resolution 1280(H)*960(V) @25/30fps / 960P (Horizontal 1500TVL)
Lens 3.6/6.0/8.0mm 2.0 Megapixel ICR Lens
Optical Filter With IR-Cut Filter removable (ICR) Design
Sync. System Internal
Scanning Sysstem 2 : 1 Interlace
Minimum Illumination 0.01 Lux color / F2.0 / 0 Lux On
SNR More than 55 dB (AGC OFF)
WDR D-WDR On / Off
Camera ID On / Off
Day / Night Ext / Auto / Color / B&W
Sense Up Off / Auto (x2 ~ x30)
Electronics Shutter Auto / Manual: 1/25(30) – 1/50,000sec. / x2 ~ x30 / FLK
White Balance AWB / ATW / AWC / INDOOR / OUTDOOR / MANUAL
Gain Control Adjustable Auto Gain Control
Backlight Compensation OFF / BLC / HSBLC
DNR 3D DNR / 2D DNR
Mask & Privacy OFF / ON (4 Mask Areas)
Motion Detection OFF / On (4 Areas)
Defog OFF / Auto
Sharpness Adjustment OFF / Auto
Brightness Adjustment Adjustable Brightness
Transmission Distance 300 / 500M over RG59/RG6U Coaxial Cable
Twisted Cable Transmission Max. 300M
Video Output AHD Video (960P / 720P) & Analog Composite Video, Switchable
Operation Temp. / Humidity -10°C ~ 50? / RH 85% or Less
Power Supply DC12V ± 10%
Weatherproof Indoor
Construction Coaxial Cable Plastic
IR Distance / Led 25M / 4pcs Array IR Led
IR Led Activation 10 Lux
Dimenstion 131(L) x 93 (H) mm
Weight 500g
Certification CE / FCC / RoHS
