Norcam NC-614 CCTV 480TVL Night Vision CCTV Camera

Image Pick-up Device: SONY 1/3“ Color CCD

Effective Picture Elements: NTSC: 537*505, PAL: 537*597 (H*V)

Horizontal Resolution: 480 horizontal TV lines

Minimum Illumination: 0 LUX with built-in IR-LED

S/N Ratio: More than 52dB

Auto Electronic Shutter NTSC:1/60s~1/100,000s, PAL:1/50s~1/110,000s

Gain Control Automatically

White Balance Automatically (2500K~9500K)

Gamma Characteristic 0.45

Lens Furnished Board Lens 6.0 mm / F2.0

Synchronous System Internal, Negative sync.

Video Output 1 VP-p Composite Video / 75 Ohms.

Power Supply 12V DC / 300 MA

Operating Temp. -10? to 50? (14? to 122?)

Water Resistance IP66

IR LED 36Units of 850nm IR LED.

IR Project Distance 25 ~ 30 Meters

Dimensions 67mm(f) *85mm (L)

========================================

Free Service: 1 Year

=+=+=+=+=+=+=+=+=+=+=+=+=+=+=+=+=+=
